Hợp bộ thử nghiệm cao áp SVS-100C KEP

Mã sản phẩm: SVS-100C |
Thương hiệu: KEP

Giá gốc:

Giá khuyến mại: Liên hệ ( Đã có VAT )

Tiết kiệm: (0%)

Hợp bộ thử nghiệm cao áp
Model: SVS-100C
Hãng: KEP
Thông tin sản phẩm

  • Technical Specifications

    General SVS-100C specifications:

  • Operating Conditions

    The device is designed for an indoors operation under the following conditions:

    Condition Value
    Air temperature, °С from +10 to +35
    Relative humidity, %, up to
    80 at +20 °С
    Atmospheric pressure, kPa (mm hg)
    84,0 – 106,7 (630 – 800)

Characteristic Value
Single-phase AC power supply voltage, V 220±22
Power supply frequency, Hz 50±2
Reduced error of voltage measurements in the range from 20 to 100 V, % ±3
Reduced error of voltage measurements in the range from 1 to 6.5 kV, % ±3
Reduced error of voltage measurements in the range from 6.5 to 15 kV, % ±3
Reduced error of voltage measurements in the range from 10 to 100 kV, % ±3
Reduced error of current measurements, % ±3
Maximum consumed power, kW 0.9
Lifespan, years, avg 10



Test basin specifications:

Characteristic Value
Maximum voltage, kV
15
Range of measurements of leakage currents, mA 0.3-7.5
Number of spaces of test subjects 4
Dimensions, mm, max 700х795х865
Net weight in dry condition, kg, max  30



Control unit specifications:

Characteristic Value
Consumed power, W, max
20
Dimensions, mm, max 316х187х132
Net weight, kg, max 3



Measuring unit specifications:

Characteristic
Value
Power consumption measuring unit + BVI, VA, max 2000
Dimensions, mm, max
330х500х380
Net weight, kg, max 27



High voltage supply BVI-50 specifications:

Characteristic Value
Range of leakage current measurements, mA
0.3...10.0
Maximum voltage, kV
50
Dimensions, mm, max 270×230×370
Net weight, kg, max 20
