Hợp bộ tìm sự cố cáp ngầm SWG-2000 KEP

Mã sản phẩm: SWG-2000 |
Thương hiệu: KEP

Giá gốc:

Giá khuyến mại: Liên hệ ( Đã có VAT )

Tiết kiệm: (0%)

Hợp bộ tìm sự cố cáp ngầm
Model: SWG-2000
Hãng: KEP
Thông tin sản phẩm

Surge wave generator SWG-2000 is designed for locating the faults in cable lines with transient resistance R >= 500 Ohm using an acoustic method in conjunction with an acoustic receiver P-900 and digital impulse reflectometer RIF-7.

Thông số kỹ thuật

  • Characteristic Value
    Сapacity of the capacitor, µF 4 х 15.0
    Maximum output voltage by stages, kV 80
    - first stage, kV 8
    - second stage, kV 16
    - third stage, kV 32
    Maximum discharge pulse energy on any stage, J
    1920
    Operating modes:
    - manual
    Yes
    - automatic (with the discharge pulse intervals, s) Yes (0,5; 1; 2; 3; 5)
    Single-phase AC power supply voltage, V
    220±22
    Power supply frequency, Hz 50±2
    Dimensions, mm
    600х1500х900
    Net weight, kg, max
    150
  • Operating Conditions

    The device is designed for an indoors operation under the following conditions:

    Condition Value
    Air temperature, °С from -10 to +40
    Relative humidity, %, up to
    80 at +20° С
    Atmospheric pressure, kPa (mm hg)
    84,0 – 106,7 (630 – 800)
    Operating staff, min 2
