| Parameter |
value |
| Сapacity of the capacitor, µF |
10 |
| Maximum output voltage, kV |
20 |
| Maximum discharge pulse energy, J |
2000 |
| Operating modes: |
| - manual |
Yes
|
| - automatic (with adjustment of discharge pulse rate) |
Yes
|
| Control Unit |
Built-in |
| Single-phase AC power supply voltage, V |
220 ± 22 |
Maximum consumed current, A
|
10 |
| Lifespan, years, min |
10 |
| Frequency, Hz |
50 ± 2 |
| Dimensions, mm |
820×630×500 |
| Weight, kg, max |
145 |
