Indication range
|
0 point - 100 point (262 degree dial scale)
|
|
Minimum indication
|
1 point (Accuracy : ±1 point)
|
|
Indentor Design (mm)
|
Height: 2.54 15 Dia. Cylindrical
|
|
Spring Forces [mN(g)]
|
0 point: 980(100)
100 point: 1960(200)
|
|
Central hole of diameter of Pressure foot
|
Φ16
|
|
Pressure foot
Dimension (mm)
|
50×37(Oval shape)
|
|
Outer Dimension (mm)
|
Approx. Width 50×Depth 37×Height 81
|
|
Weight (g)
|
300
|
|
Application
|
Powder puff
|
