model
|
KDS800-150A
|
|
KDS800-650
|
KDS800-1200
|
|
temperature range
|
-20℃~150℃
|
|
50℃~650℃
|
300℃~1200℃
|
|
heating rate
|
30~100:20min
30~150:40min
|
|
30~300:7min
30-400:12min
30~650:25min
|
30~1200:75min
|
|
Display accuracy
|
≤±0.1℃
|
|
Below 400℃：≤±0.35℃
400-650℃：≤±0.5℃
|
≤±1.2℃
|
|
Insertion depth
|
160mm
|
150mm
|
135mm
|
|
Average heat block diameter
|
36mm
|
|
32mm
|
39mm
|
|
Temperature field stability
|
≤±0.02℃
|
|
≤±0.05℃
|
≤±0.2℃
|
|
Horizontal temperature field
|
≤±0.05℃
|
|
≤±0.05℃
|
≤±0.25℃
|
|
Vertical temperature field
|
The deviation in the range of 50mm calculated from the bottom of the hole of the soaking block is 1 degree
|
|
Temperature unit
|
℃ or ℉
|
|
Temp Accuracy
|
0.2%
|
|
Display resolution
|
0.1℃
|
|
0.1℃
|
0.1℃
|
|
maximum power
|
Negative temperature type: 500W, medium temperature type: 800W, high temperature type: 3000W
|
|
weight(Net weight)
|
Negative temperature type: 13kg, medium temperature type: 11kg, high temperature type: 11kg
|
|
weight (Containing packaging)
|
Negative temperature type: 23kg, medium temperature type: 18kg, high temperature type:20kg Packaging includes aluminium box and transport wooden box
|
|
Outline size
|
Negative temperature type and high temperature type: 310*190*340mm, medium temperature type: 250*150*310mm
|
|
Use environment
|
Ambient temperature 0-50℃, relative humidity less than 95% (no condensation)
|
|
Power supply
|
220VAC ± 10%, 45 ~ 60Hz, optional 110VAC ± 10%.
|
|
|
|
