- Temperature range: -20 °C to +350 °C
- Accuracy: ± 2 °C, ± 2 % of the measurement value
- Detector type: focal plane array (FPA), uncooled microbolometer
- Detector resolution; 160 x 120 Pixel
- Spectral range: 8 to 14 µm
- Field of vision (FOV): 21° x 28°
- Geometrical resolution: 3 mrad
- Thermal sensitivity: ≤ 0.08 °C with 30 °C
- Refresh rate: 25 Hz
- Focus / min. Focus distance: fixed / 0.5 m
- Digital photo camera: 8 megapixels, integrated picture lamp (LED)
- Display: 5 inches touch display, capacitive
- Display: pseudocolor, 6 color palettes (IR-picture); 16.7 million colours (real picture)
- Display options: IR picture, IR video, real picture
- Measuring points: five movable temperature measuring pints, each to be configured freely as MIN, MAX or ALARM
- Measurement functions: isotherms, field analysis (circle, square), line analysis, alarm function
- Emissivity: user-defined variable adjustable from 00.1 up to 1.0
- Measure correction: correction of the reflecting object temperature; automatic corrections with integrated thermographic analysis software, report function, IR video player, internet browser
- Interfaces: USB 2.0, WLAN, GPS, Bluetooth
- Data storage: 21 GB intern flash storage
- File formate: radiometric picture (14-bit-JPEG); visual picture (JPEG), not radiometric thermographic video (MPEG-4)
- Battery type: standart, Li-Ion; rechargeable
- Operating type: ≈ 2h
- Workspace temperature: -20 °C up to +50 °C
- Protection class: IP54
- Shock / vibration: 174 x 102 x 35 mm
- Weight: 405 g
