- Development, design, production: 100% TROTEC
- High precision - rapid response time
- Large temperature range between -50°C and +1,850°C
- Dual laser technology for measuring spot diameter display
- Freely-selectable degree of emission from 0.1 to 1.0
- Alarm function and a plurality of demanding added functions
- Backlit display

Thông số kỹ thuật

- Accuracy
± 3°C at -50°C to 20°C
± 1% or 1°C at 20°C to 500°C
± 1.5% or 2°C at 500°C to 1,000°C
± 2% at 1,000°C to 1,850°C

- Reproducibility
± 1.5°C at -50°C to 20°C
± 0.5% or ± 0.5°C at 20 °C to 1,000 °C
± 1% at 1,000°C to 1,850 °C

-Optical resolution (D:S): 75:1
-Smallest measurement spot: 18 mm @ 1,350 mm
-Temperature range: -50°C to +1,850°C
-Reaction time: < 150 ms
-Spectral sensivity: 8 ~ 14 µm
-Laser class: Klasse 2 (II)
-Wavelength: 630 ~ 670 nm
-Power: <1 mW
-Display: LCD, monochrome
-Temperature range (contact-temperature sensor): 50°C to +300°C
-Accuracy (contact-temperature sensor): ±1,5% or ± 3°C
-Reproducibility (contact-temperature sensor): ± 1.5%
-Operating conditions (operation): 0°C to 50°C, 10% to 90% RH
-Operating conditions (storage): -10°C to 60°C, < 80% RH (non-condensing)
-Power supply (internal): 9 V IEC 6LR61
-Power supply (external): via USB
-Switchable dual-laser
-Temperature units switchover function: °C / °F
-Resolution: 0.1 °C
-Permanent measurement function
-Minimum value indicator
-Maximum value indicator
-Differential value display
-Average value display
-Hold displayed value
-Alarm function with userdefined threshold values
-Degree of emission is adjustable from 0.1 to 1.0
-Backlit LCD display
-Automatic switch off
-Maximum value indicator
-Open target eyepiece
-Saveable measuring values: 100
-Additional temperature measurements: with external type K sensor
-Can be used for software-supported measurement series
-USB port
-Tripod socket ¼-inch - 20 UNC
-Dimensions (L x W x H): 168 x 56 x 225 mm
-Weight: 350 g
-Housing: plastic
