- Temperature range: -20 °C to +600 °C
- Accuracy: ± 2 °C, ± 2 % of the measurement value
- Detector type: focal plane array (FPA), uncooled microbolometer
- Detector resolution; 384 x 288 Pixel
- Spectral range: 7.5 to 14 µm
- Field of vision (FOV): 24° x 18°
- Geometrical resolution: 1.1 mrad
- Thermal sensitivity: ≤ 0.05 °C with 30 °C
- Display refresh rate: 50 / 60 Hz
- Focus /min. focus distance: manual / 0.5 m
- Display: 3.5 inches touch LCD, capacitive
- Laser type: semiconductor AlGalnP diode laser class 2, 1 mw/635 nm red
- Battery type: standard Li-Ion, rechargeable, replaceable
- Operating time: ≈ 3 h
- Power supply operation: 8 – 11 V DC
- Operating temperature: -20 °C to +50 °C
- Storage temperature: -40 °C to +70 °C
- Air moisture: 10% to 95% room humidity /non condensing)
- Protection class: IP 54 IEC 529
- Shockproof: 25G IEC 68-2-29
- Vibrationproof: 2G IEC 68-2-6
- Dimensions: 230 x 80 x 195 mm
- Weight: 650 g
- Interface: USB 2.0, Bluetooth, analog video (PAL/NTSC)
