Test Voltage
100 V - 250 V - 500 V - 1,000 V directly, one button selectable.
100 V to 1 kV in 50 V increments.
DC, negative.
Nominal test voltages
250 V - 500 V - 1,000 V.
Negative, DC voltage.
Resistance measurement range
From 10 kΩ up to 200,000 MΩ.
Short circuit current
1.5 ± 0.3 mA.
Test Voltage Accuracy
-0 / +15% for resistances between 10 MΩ and open circuit.
Basic Accuracy
R ≤ 50 GΩ: ±5% of reading ± 2 digits.
R > 50 GΩ: ±10% of reading ± 2 digits.
Low resistance measurement and continuity tester
Range: 0.05 Ω to 150 Ω.
Accuracy: ±5% of reading ± 2 digits.
Test current: up to 200 mA.
Continuity indicator: Activates at R < 5 Ω ± 0.5 Ω.
Built-in timer
5 - 10 - 15 - 30 seconds.
1 - 2 - 3 - 5 - 10 - 15 minutes.
Pass / fail test
1 - 2 - 5 - 10 - 20 - 50 - 100 - 200 - 500 MΩ.
1 - 2 - 5 - 10 - 20 - 50 - 100 GΩ.
Voltmeter
True RMS.
Range: 0 - 600 V CA/CC.
Accuracy: ±3% of reading ± 2 digits.
Overvoltage Protection
600 V.
Additional Features
Guard terminal.
Automatic Polarization Index.
Hold function.
Safety class
In accordance with IEC 61010‑1.
E.M.C.
In accordance with IEC 61326-1.
Electrostatic Immunity
In accordance with IEC 61000-4-2.
Power Supply
Built-in, NiMH battery.
Autonomy: 1,000 tests of 5 seconds with an interval of 25 seconds according IEC 61557-2. During the measurement is used a test resistance wich the value is UN x (1,000 Ω / V).
Battery charger
Built-in, with external power supply of 12 V - 2 A.
Operation temperature
-5 °C to 50 °C.
Storage temperature
-10 °C to 70 °C.
Humidity
95% UR (without condensation).
Equipament Weight
Approx. 0.5 kg.
Dimension
102 x 195 x 46 mm.
