Test Voltage
100 V - 250 V - 500 V - 1,000 V directly, one button selectable.
100 V to 1 kV in 50 V increments.
DC, negative.
Maximum resistance reading
500 GΩ @ 100 V up to 500 V.
1 TΩ @ 525 V up to 1,000 V.
Short circuit current
1.5 ± 0.5 mA.
Test voltage accuracy
± 3% of nominal test voltages on 10 GΩ.
Equipment Basic Accuracy
± 5% of reading ± 3 digits.
(1 MΩ to 500 GΩ at any test voltage).
Advanced features
Automated Polarization Index calculation.
Automated Dielectric Absorption Ratio calculation.
Programmable Pass-Fail test.
Programmable Timer.
Built-in printer
Prints elapsed time, actual voltage and resistance measured each 15 seconds.
Interface
USB.
Built-in chronometer
Shows elapsed time in mm:ss format. Count starts automatically for each measurement.
Environmental protection
IP54 with closed lid.
MegaLogg2 Software
Friendly, easy to use software. Tests are represented in graphic and tabular views. With automatic report generator, including the operator's commentaries.
Safety class
In accordance with IEC 61010-1.
E.M.C.
In accordance with IEC 61326-1.
Electromagnetic irradiation immunity
In accordance with IEC 61000-4-3.
Electrostatic immunity
In accordance with IEC 61000-4-2
Power supply
Internal rechargeable LFP battery (LiFePO4 12 V - 3000 mAh).
Battery charger
AC Adapter (12 V - 2.0 A).
Battery life
6 hours (typical) testing at 500 V @ 10 GΩ load.
Operating temperature range
-5 °C to 50 °C.
Storage temperature range
-25 °C to 70 °C.
Humidity range
95% RH (non condensing).
Equipment weight
Approx. 2.7 kg.
Dimension
274 x 250 x 124 mm.
