Test Voltages
500 V, 1,000 V, 2,500 V, 5,000 V directly, one button selectable.
500 V to 5 kV in 100 V or 500 V increments.
DC, negative.
Maximum resistance reading
5 TΩ @ 5 kV.
Short circuit current
1.5 ± 0.5 mA.
Megohmmeter basic accuracy
± 5% of reading from 1 MΩ up to 1 TΩ.
± 20% of reading from 1 TΩ up to 5 TΩ.
Advanced features
Automated Polarization Index calculation.
Automated Dielectric Absorption Ratio calculation.
Step Voltage Test.
Memory for 4,000 measured values.
Programmable Pass-Fail test.
Built-in printer
Prints elapsed time, actual voltage and resistance measured each 15 seconds.
Interface
USB.
Built-in chronometer
Shows elapse time in mm:ss format. Count starts automatically for each measurement.
Environmental protection
IP54 with close lid.
Safety Class
In accordance with IEC 61010-1.
E.M.C.
In accordance with 61326-1.
Elestrostatic immunity
In accordance with 61000-4-3.
Electrostatic immunity
In accordance with IEC 61000-4-2.
Power supply
Internal rechargeable 12 V - 3 Ah battery.
Battery charger
For 100 - 240 V~ mains supply.
Operating temperature range
-5 °C to 50 °C.
Storage temperature range
-25 °C to 70 °C.
Humidity range
95 % RH (non condensing).
Equipment weight
Approx. 3.6 kg.
Dimension
274 x 250 x 124 mm.
