| Oscilloscope – vertical (analog) |
9300-15 models |
9300-20 models |
9300-25 models |
| Number of channels |
PicoScope 9341: 4 |
| All other models: 2 |
| Acquisition timing |
Selectable simultaneous or alternate acquisition |
| Bandwidth, Full |
15 GHz |
20 GHz |
25 GHz |
| Bandwidth, Narrow |
8 GHz |
10 GHz |
12 GHz |
| Pulse response rise time, full bandwidth |
23.4 ps (10% to 90%, calculated) |
17.5 ps (10% to 90%, calculated) |
14.0 ps (10% to 90%, calculated) |
| Pulse response rise time, narrow bandwidth |
43.8 ps (10% to 90%, calculated) |
35.0 ps (10% to 90%, calculated) |
29.2 ps (10% to 90%, calculated) |
| Noise, full bandwidth |
< 1.2 mV RMS typical, < 1.6 mV RMS maximum |
< 1.5 mV RMS typical, < 2.0 mV RMS maximum |
< 1.9 mV RMS typical, < 2.5 mV RMS maximum |
| Noise, narrow bandwidth |
< 0.7 mV RMS typical, < 0.9 mV RMS maximum |
< 0.8 mV RMS typical, < 1.1 mV RMS maximum |
< 1.0 mV RMS typical, < 1.3 mV RMS maximum |
| Noise with averaging |
100 μV RMS system limit, typical |
| Operating input voltage with digital feedback |
1 V p-p with ±1 V range (single-valued) |
