Construction
1.5 mm powder coated steel. Flexible mounting brackets.
Dimensions
158.30 x 105.25 x 277 mm (W x H x D). 208.30 mm W including mounting brackets.
Electrical Output
30 kV max, 20 W. 1 mA @ 20 kV and 0.67 mA @ 30 kV. Output voltage adjustable in 0.1 kV steps. Current limit adjustable in 0.01 mA steps. Positive or negative polarity to be specified at time of order.
HV Connections
4 generator electrodes can be connected.
External Control and Monitoring
Remote interface for comprehensive control and monitoring with standard 25-way, D-type connection.
Electrical Input
24 V DC. 2 A max. 48 W max. Combicon or 4-pin M12 connector. 90 - 250 V AC, 50/60 Hz, 1 A. IEC 60320 C14 inlet. Mating plug IEC 60320 C13.
Safety
Protected against overload, short-circuit, sparking and mis-wiring.
Environmental
Dry, oil-free location. 0 - 50 ᵒC maximum temperature, 70 % rH non-condensing max. IP20.
Certification
CE, CB and UL.
Options
IML variant - limited to 20 kV output.
