- Laser diode life: 8,000 operating hours MTBF (1 year warranty)
- Operating Range up to 25 feet (7.6 meters) and 60 degrees offset from target
- Humidity Maximum relative humidity 80% for temperature up to 88 deg. F (31 deg. C)
- decreasing linearly to 50% rlatie humidity 104 deg. F (40 deg. C)
- Power Requirement 3.0 - 24 Vdc, 0.13 Watts
- Output Poistive pulse when target present - Output Voltage = Supply Voltage
- Operating Temp 14 deg. F to 158 deg. F (-10 deg. C to 70 deg. C)
- Connection 3.5 mm (1/8 inch) male stereo plug (ROLS-P) or
- Tinned wires (ROLS-W)
- Pulse Duration: Continuous
- Laser Wavelength: 650 nm
- Speed Range 1-250,000 RPM
- Maximum Laser Output: 1mW
- Beam Divergence: <1.5 mrad
- Beam Diameter: 4 x 7 mm typical at 2 meters
- Material 303 Stainless Steel supplied with two M18 jam nuts and mounting bracket
- Lens Acrylic Plastic
- Visible Red Laser, Class 2 (per IEC 60825-1 Ed 1.2 2001-8) Complies with FDA perfomance standards for laser products except for deviations pursuant to Laser Notice 50, dated July 26, 2001
- Dimensions Threaded tube 3.12 in x 0.71 in diameter (M18 x 1.5 x 79.4 mm) long
