| Rated Primary Current |
AC20A |
| Applicable Current |
0.01mA～20A |
| Max. Capable Current |
30A |
| Secondary Windings |
Leakage Current（Red/Black）1600Turns
Load Current（White/Green）3200Turns |
| CT Inside Diameter |
φ30mm |
| Applicable Frequency |
10Hz～5kHz |
| Output Example |
AC29.7mV±2%（10A/10Ω/White・Green） |
| Recommendable Load Resistor |
10Ω |
| Output Part |
Lead Wire： Approx. 200mm |
| Rated Voltage |
Less than AC600V for low voltage circuit of coated wires |
| Withstanding Voltage |
AC2200V/1 minute (between output terminal and CT) |
| Insulation Resistance |
More than 100MΩ by 500V insulation tester (between output terminal and CT) |
| Operation Temperature |
0～60℃, less than 80%RH w/o condensation |
| Dimension |
58×158×23mm |
| Weight |
Approx. 105g
|
