| Rated Primary Current |
AC3000A |
| Applicable Current |
1mA～3000A |
| Max. Capable Current |
3600A |
| Secondary Windings |
1mA～30A （Red/Black） 3080Turns
30A～3000A（White/Green） 2000Turns |
| CT Inside Diameter |
128×108mm |
| Applicable Frequency |
10Hz～5kHz |
| Output Example |
AC51.1mV±2%（10A/10Ω/White・Green） |
| Recommendable Load Resistor |
1～200Ω |
| Output Part |
Lead Wire： Approx. 1000mm |
| Rated Voltage |
Less than AC600V for low voltage circuit of coated wires |
| Withstanding Voltage |
AC2200V/1 minute (between output terminal and CT) |
| Insulation Resistance |
More than 100MΩ by 500V insulation tester (between output terminal and CT) |
| Operation Temperature |
0～60℃, less than 80%RH w/o condensation |
| Dimension |
194×341.5×52mm |
| Weight |
Approx. 1800g
|
