| Rated Primary Current |
AC100A（50/60Hz） |
| Applicable Current |
1mA～100A |
| Max. Capable Current |
100A |
| Nominal CT Ratio |
2060:1 |
| CT Inside Diameter |
φ22mm |
| Applicable Frequency |
10Hz～5kHz |
| Output Example |
AC19.4mV±2%（200mA/200Ω） |
| Output Part |
Lead Wire： Approx. 4000mm （with Y Terminal: V1.25-B3A） |
| Rated Voltage |
Less than AC600V for low voltage circuit of coated wires |
| Withstanding Voltage |
AC2200V/1 minute (between output terminal and CT) |
| Insulation Resistance |
More than 100MΩ by 500V insulation tester (between output terminal and CT) |
| Operation Temperature |
-10～60℃, less than 80%RH w/o condensation |
| Dimension |
54×58×29.5mm |
| Weight |
Approx. 200g |
| Standard |
Compliant with RoHS directive
|
