| Measuring function |
AC load current |
| Measuring Range |
AC 0～20A/600A (50Hz/60Hz), 2 ranges manual |
| Jaw opening capability |
φ35mm |
| Accuracy |
Range/Resolution/Accuracy(50/60Hz)
AC 20A/0.01A/±2%rdg±8dgt
AC 600A/1A/0～400A : ±2%rdg±9dgt 400A～600A : ±3%rdg±10dgt
(23℃±5℃ 80%RH or less) |
| Limitation of circuit voltage |
AC 80Vrms to 7000Vrms |
| Insulation Resistance |
100MΩ or more by DC 1000V insulation tester
(Between operation handle and core of CT) |
| Withstanding Voltage |
AC 15kV, 1 minute
(Between operation handle and core of CT) |
| Size and Weight |
70(W)×356(H)×32(D)mm, Approx. 370gs. |
| Operating Temperature |
0～40℃, less than 80%RH without condensation |
| Power supply |
AAA size battery×2 |
| Accessories |
Carrying case:1
Instruction manual:1
Batteries:2
|
