| Measuring Function |
AC/DC Current (RMS), AC/DC Voltage,
DC Current in AC Circuit |
| CT Inside Diam. |
φ23mm |
| Measuring Range |
AC Current:15A/150A
DC Current:15A/150A
AC Voltage:150V/600V
DC Voltage:150V/600V
DC Current in AC:% Display |
| Accuracy |
AC Current (15A):±1.0%rdg±5dgt
AC Current (150A):±2.0%rdg±5dgt
DC Current (15A):±1.0%rdg±5dgt
DC Current (150A):±2.0%rdg±8dgt
AC/DC Voltage:±1.0%rdg±5dgt |
| Other Functions |
Data Hold, Auto Power Off, One Push 0Adjust. |
| Safety Standard |
IEC1010-1 CATⅡ600V |
| Power Supply |
AAA Size Alkaline Battery × 3 |
| Dimension |
W48×H178×D24mm |
| Weight |
Approx. 120g |
| Accessories |
Soft case:1
Instruction manual:1
Test lead:1
Batteries:2
|
