| Measuring method |
Dual slope integration mode |
| Display |
3.5 digit LCD, max. reading of 1999 |
| Sampling |
2 times/sec |
| Range |
AC 0～2000mA ( Leakage current)
AC 0～800A (Load current) |
| Accuracy |
±1.0% rdg ± 5 dgt |
| Filter |
Low pass filter(130Hz) |
| Data output |
DC100mV (for full scale) |
| Power supply |
1.5V (AM-4, LR03 or AAA)×2 |
| Operating temperature |
0℃ to 40℃, 80%RH max. (Without condensation) |
| Storage temperature |
10℃ to 60℃, 70%RH max. (Without condensation) |
| Size |
130(W)×200(H)×38(D)mm |
| Weight |
Approx. 500g
|
