Measuring method |
Dual slope integration mode |
Display |
3.5 digit LCD, max. reading of 1999 |
Accuracy |
23℃±5℃ 80%RH or less (50/60Hz)
Function/Range/Resolution/Accuracy
AC Current/0.2A/0.1mA/±1.0% rdg ± 5 dgt
AC Current/2A/1mA/±1.0% rdg ± 5 dgt
AC Current/20A/0.01A/±1.0% rdg ± 5 dgt
AC Current/200A/0.1A/±1.0% rdg ± 5 dgt
AC Current/400A/1A/±1.0% rdg ± 5 dgt
AC Voltage/600V/1V/±1.0% rdg ± 5 dgt
Resistance/2kΩ/1Ω/±1.0% rdg±3% of full scale
Resistance/2MΩ/1kΩ/±1.0% rdg±3% of full scale |
Jaw opening capability |
40mmφ |
Over range indication |
Blanking of all digits except MSD 1 |
Low battery indication |
"B" mark on LCD |
Data hold indication |
“D・H“ mark on LCD |
Sampling |
2 times/sec |
Limitation of circuit voltage |
Less than AC 600V |
Affection of magnetic field |
3mA or less (at 100A nearby conductor) |
Operating Temperature |
0℃ to 40℃, 80%RH max. ( Without condensation ) |
Storage Temperature |
-10℃ to 60℃, 70%RH max. ( Without condensation ) |
Power supply |
1.5V (AM-4, LR03 or AAA)×2 |
Size |
69(W)×197(H)×32(D)mm |
Weight |
Approx. 370g |
Accessories |
Hard carrying case:1
Instruction manual:1
Test lead:1set
Batteries:2
|
