| Rated Primary Current |
DC/AC400mA |
| Applicable Current |
0～±800mA |
| Max. Capable Current |
±800mA |
| CT Inside Diameter |
φ11mm |
| Applicable Frequency |
DC, 40Hz～18kHz |
| Output Voltage |
±5V F.S |
| Accuracy |
±1% F.S |
| Response Time |
Approx. 60ms |
| Power Supply |
DC±15V±5% (Bipolar) |
| Power Consumption |
Approx. 30mA |
| Wiring Method |
M:Output COM:COM -Vcc:-15V +Vcc:+15V |
| Rated Voltage |
Less than DC/AC500V for low voltage circuit of coated wires |
| Withstanding Voltage |
AC2500V/1 minute (between output terminal and outer case) |
| Insulation Resistance |
More than 500MΩ by 500V insulation tester (between output terminal and CT) |
| Operation Temperature |
-20～85℃, less than 75%RH w/o condensation |
| Dimension |
30×30×19.2mm |
| Weight |
Approx. 25g |
| Environmental Standard |
Conforming RoHS Directive
|
