| Rated Primary Current |
DC/AC300mA |
| Applicable Current |
0～±500mA |
| Max. Capable Current |
±500mA |
| CT Inside Diameter |
φ20mm |
| Applicable Frequency |
DC～3.5kHz |
| Output Voltage |
1200mV F.S (between Ref. and Out.) |
| Accuracy |
±1.9% F.S |
| Response Time |
Approx. 50μs |
| Power Supply |
+5V±5%(Unipolar) |
| Power Consumption |
Approx. 17.5mA |
| Wiring Method |
+:+5V 0V:COM Ref:Ref Out:Output |
| Rated Voltage |
Less than DC/AC600V for low voltage circuit of coated wires |
| Withstanding Voltage |
AC5400V/1 minute (between output terminal and CT) |
| Insulation Resistance |
More than 100MΩ by 500V insulation tester (between output terminal and CT) |
| Operation Temperature |
-40～105℃, less than 75%RH w/o condensation |
| Dimension |
44.8×44.7×17.9mm |
| Weight |
Approx. 30g |
| Standard |
Compliant with RoHS directive
|
