Bộ chuyển đổi dòng điện CAMILLE BAUER SINEAX I538
Transducer for the conversion of the difference in phase angle from two electrical systems requiring synchronization into a direct current or voltage signal which is proportional to the measured value.
Measurement inputs for sinusoidal, square-wave or distorted nominal input voltages with dominant fundamental wave
Generator and bus bar input voltage: 10 to 690 V
Nominal input frequency: 50 Hz
Auxiliary power: 85 to 230 V AC/DC
Input frequency response time periods: 4
Measuring range limits: ± 10° to < ± 180° el
Measurement output available with unipolar, bipolar or live-zero output quantities
Measuring method: acquires distance between zero-crossings
Power supply: integrated AC-DC power pack with large tolerance range for universal use
Housing for top-hat rail mounting
Certifications: CSA
