| Temperature & Universal Transmitters |
| Sineax V 611 Ultra-Slim Temperature Transmitter |
Input: Thermocouple or RTD
Output: 4-20 mA or 20-4 mA
- 9 mm (0.35") wide
- PC Programmable
- Reverse Output Capable (20-4 mA)
- 100 Ohm RTD, 2, 3, or 4-wire
- T/C J, K, T, E, R, S,N, B, L, U, W5, W3
- Input Linearization
- Non-Isolated
- Internal or External CJC
- Supply Voltage: 12-30 VDC from Output Loop
 Data Sheet
Instructions
V600Plus Software |
|
| Sineax V 608 Temperature Transmitter |
Input: Thermocouple, RTD
Output: 4-20 mA
- PC Programmable
- Programmable Sensor Fault Response
- Non-Isolated
- 12-30 VDC Loop-Powered
Data Sheet
Instructions
V600Plus Software |
|
| Sineax V 624 Programmable Temperature Transmitter |
Input: Thermocouple, RTD, Thermistor, Custom
Output: 0-2 mA to 0-20 mA, 20-0 mA, 0-1 V to 0-10 V, 10-0 V
- PC Programmable
- Reverse Output Programmable
- Custom Input Linearization
- Programmable Sensor Fault Response
- Removable Plugs
- 3.7 kV Input/Output/Power Isolation
- Supply Voltage: 24-60 or 85-230 VAC/VDC
Data Sheet
Instructions
V624 external CJC
V624 internal CJC
V600Plus Software |
|
| Sineax V 604s Programmable Universal Transmitter |
Two Inputs: ±1000 mVDC to ±300 VDC, ±50 mADC, Thermocouple, RTD, Thermistor or Potentiometer 0-5kΩ
Two Outputs (common ground): 0-5 mA to ±40 mA, 0-4 V to -12~+15 V
Relay: One Relay
Communications: Modbus
- PC programmable
- Unipolar or bipolar input and output
- Reverse output programmable
- Custom input linearization
- Programmable math functions (+, -, x, Δ, min, max, mean, dx/dt)
- Programmable sensor redundancy function
- Programmable alarm relay with delay fucntion
- 3.7 kV input/output/power isolation
- Supply voltage: 24-230 VDC or 100-230 VAC
Brochure
Data Sheet
Instructions
Safety Instructions
CB Manager Software |
|
| Sineax VB 604s Programmable Universal Transmitter w. Remote I/O |
Two Inputs: ±1000 mVDC to ±300 VDC, ±50 mADC, Thermocouple, RTD, Thermistor or Potentiometer 0-5kΩ
Two Outputs (common ground): 0-5 mA to ±40 mA, 0-4 V to -12~+15 V
Relay: One Relay
Communications: Control of Relay and Outputs via Modbus
- Ability to control relay and output via Modbus
- PC programmable
- Unipolar or bipolar input and output
- Reverse output programmable
- Custom input linearization
- Programmable math functions (+, -, x, Δ, min, max, mean, dx/dt)
- Programmable sensor redundancy function
- Programmable alarm relay with delay fucntion
- 3.7 kV input/output/power isolation
- Supply voltage: 24-230 VDC or 100-230 VAC
Data Sheet
Instructions
Safety Instructions
CB Manager Software USB Driver |
|
