The Process Timer TCT101 ia a panel mount instrument which is available in several different options. The TCT101-1ABC is a Digital Timer, The TCT-2ABC is a Counter and the TCT-3ABC is a Digital Tachometer. The TCT101-4ABC-T is a combination of all the options ie it can be a Timer or Counter or a Tachometer, available by programming. It also has the option of having a Modbus RS485 output. The TCT101-1ABC has two 4 digit displays and can be set up to switch on a relay after a certain time or switch off a relay after a certain time. The timer period could be 1/100 S or 1/10 S or seconds or minutes or hours. By selecting the keys or by a digital input it is possible to interrupt the timer. The unit can also be set to toggle on and off over a period of time.
The Process Counter TCT201 is a 1/16Din 48 x 48 mm panel mount instrument which is available in three different options. The TCT201-1ABC is a Digital Timer, The TCT201-2ABC is a Counter and the TCT201-3ABC is a Digital Tachometer. The TCT201-1ABC has two 4 digit displays and can be set up to switch on a relay after a certain time, or switch off a relay after a certain time. By selecting the keys or by a digital input it is possible to interrupt the timer. The unit can also be set to toggle on and off over a period of time.
TCT101-1ABC
2.91 X 1.25" 74 x 32 mm.
Input NPN, PNP, TTL
Output up to 2 Relays
TCT101-2ABC
2.91 X 1.25" 74 x 32 mm.
Input NPN, PNP, TTL
Output up to 2 Relays
TCT101-3ABC
2.91 X 1.25" 74 x 32 mm.
Input NPN, PNP, TTL
Output up to 2 Relays
TCT101-4ABC-T
2.91 X 1.25" 74 x 32 mm.
Input NPN, PNP,TTL
Output 1 Relay
Modbus RTU
