| Item |
Specification |
| Model Name |
RCP-200 |
| Memory unit model name |
RCM-G |
| Measuring Temp. Range |
0 - 300C |
| Measuring Points |
1 - 6 points |
| Max Measuring Time |
Approx. 90 min. (Sampling Time:0.5 sec.)
Approx. 15 min. (Sampling Time:0.05 sec.) |
| Sampling Time |
0.05, 0.1, 0.2, 0.5, 1.0, 2.0, 4.0 & 8.0 sec. (Arbitrary setup possible) |
| Temp. Accuracy |
+/-2C |
| Input |
Thermocouple JIS-K 110Ω max. |
| Power Supply |
Lithiu Ion Rechargeable Battery |
| Outer Dimension |
200(W) x 50(D) x 15(H)(mm) |
| Figure |
Figure |
| Weight |
Approx. 400g |
| Data Transmission Method |
USB |
| Reflow Profile Analysis Software |
TMR-1 |
