Bộ giũa kỹ thuật TSUBOSAN

Bộ giũa kỹ thuật TSUBOSAN

Bộ giũa kỹ thuật TSUBOSAN

Hand

Name	Length		Roots w×t mm	Tip	Tong mm	number of input pcs	ITEM NO.
150m/m	6	150	16×4	14×2.5	40	12	HI150**
200m/m	8	200	21×5	19×3	50	6	HI200**
250m/m	10	250	25×6	22×4	60	6	HI250**
300m/m	12	300	30×7	26×5	70	6	HI300**
350m/m	14	350	34×7.5	30×5.5	80	6	HI350**
400m/m	16	400	36×8.5	32×6.5	90	6	HI400**

Page Top

Half Round

Name	Length INCH mm		Roots w×t mm	Tip w×t mm	Tong mm	number of input pcs	ITEM NO.
150m/m	6	150	16×4.5	8.5×3.3	40	12	HA150**
200m/m	8	200	21×6	12×4.3	50	6	HA200**
250m/m	10	250	25×7	15×5.5	60	6	HA250**
300m/m	12	300	30×8.5	17×6.5	70	6	HA300**
350m/m	14	350	34×10	19×6.8	80	6	HA350**
400m/m	16	400	36×11	20×7	90	6	HA400**

Page Top

Round

Name	Length		Roots w mm	Tip	Tong mm	number of input pcs	ITEM NO.
150m/m	6	150	φ6	φ3.3	40	12	MA150**
200m/m	8	200	φ8	φ4.2	50	6	MA200**
250m/m	10	250	φ10	φ5.2	60	6	MA250**
300m/m	12	300	φ12	φ6.5	70	6	MA300**
350m/m	14	350	φ15	φ8	80	6	MA350**
400m/m	16	400	φ18	φ10	90	6	MA400**

Page Top

Square

Name	Length INCH mm		Roots w mm	Tip w mm	Tong mm	number of input pcs	ITEM NO.
150m/m	6	150	6	8.5×3.3	40	12	KA150**
200m/m	8	200	8	12×4.3	50	6	KA200**
250m/m	10	250	10	15×5.5	60	6	KA250**
300m/m	12	300	12	17×6.5	70	6	KA300**
350m/m	14	350	15	19×6.8	80	6	KA350**
400m/m	16	400	18	20×7	90	6	KA400**

Page Top

Triangular

Name	Length		Roots w mm	Tip	Tong mm	number of input pcs	ITEM NO.
150m/m	6	150	12	7	40	12	SA150**
200m/m	8	200	15	8.5	50	6	SA200**
250m/m	10	250	17	10	60	6	SA250**
300m/m	12	300	12	12	70	6	SA300**
350m/m	14	350	22	13	80	6	SA350**
400m/m	16	400	(25)	(14)	(90)	(6)	(SA400**)

Page Top

Oval

Name	Length INCH mm		Roots w×t mm	Tip w×t mm	Tong mm	number of input pcs	ITEM NO.
150m/m	6	150	10×5.5	6.5×3.6	40	12	DE150**
200m/m	8	200	12×8	7.8×5.2	50	6	DE200**
250m/m	10	250	15×10	9.8×6.5	60	6	DE250**
300m/m	12	300	18×12	12×8	70	6	DE300**
350m/m	14	350	20×15	14×10	80	6	DE350**

Page Top

FILES FOR STAINLESS

Page Top

UNI-CUT FILES

Page Top

100mm ENGINEER'S FILES

*Roughness of cutting is varied by last two digits of the item no.
Example: HI015001→150mm hand Bastard
*knowledge
In most cases, W-cut (Double) is used.

*Roughness of cutting is varied by last two digits of the item no.
Example: HI015001→150mm hand Bastard
*knowledge
In most cases, W-cut (Double) is used.

*Roughness of cutting is varied by last two digits of the item no.
Example: HI015001→150mm hand Bastard
*knowledge
In most cases, W-cut (Double) is used.
