| Application sensor |
Torque : Strain gauge type Torque sensor
RPM : Proximity sensor |
| Sensor authorized voltage |
Torque : DC 10V
RPM : DC 12V |
| Zero adjustment range |
Torque : 100% F.S (Auto Zero) |
| Signal input range |
Torque : 0 ~ 3mV/V |
| Input pulse number |
1 ~ 350 pulse/circle |
| Display |
Torque : -19999 ~ +32767
RPM : 0 ~ 60000 |
| Character height |
7 segment 5 digit LED 15mm |
| A/D |
Torque : 16bit 100 times/sec |
| Zero variation |
Torque : within 0.5μ V/℃ |
| Sensitivity variation |
Torque : within 0.01%/℃ |
| Voltage output |
Voltage torque & rpm 0 ~ 10V (4 ~ 20mA available by internal operation) |
| Contact capacity |
AC 250V 0.5A, DC 50V 1A |
| Relay life span |
over 20 million times |
| Usage temperature range |
-10℃ ~ 60℃ |
| Humidity |
less than 80% RH (no dew condensation) |
| Supply power |
AC 220V 50/60Hz (AC 110V available by internal operation) |
| External size |
97 × 97 × 141mm |
| Cutting size |
92.5 × 92.5mm |
| Weigth |
About 1000 g |
