| Input inpedance |
100 kΩ (1 kΩ, 250Ω or infinite are changeable internally.)
|
| Input range |
0 V ~ 1 V (0 V ~ 10 V or 4 mA ~ 20 mA are changeable internally) |
| Number of set point |
2 points |
| Setting method |
3 digits digital switch |
| Setting configuration |
UPPER : Setting of upper limit,
LOWER : Setting of lower or upper limit (Changeable internally) |
| Output |
2 points C contact with no voltage (AC250 V, DC30 V, 0.5 A) |
| Accuracy |
within ±0.2 %F.S. |
| Hysteresis |
0 % ~ 7 %F.S. (Internal adjustment)
|
| Operating Temp. /humidity range |
0 ℃ ~ 50 ℃, 85 %RH or less (Non condensing) |
| Power supply voltage |
AC100 V (AC90 V ~ AC110 V) 50/60 Hz |
| Power consumption |
Approx. 4 VA (at AC100 V) |
| Outline dimensions |
W:42 mm × H:176 mm × D:164.4 mm (excluding protrusion)
|
| Weight |
Approx. 1.2 kg
|
