| Technical data |
Unit |
RZ 2.5 |
| Number of stages |
|
2 |
| Max. pumping speed at 50/60 Hz |
m3/h |
2.3 / 2.8 |
| Max. pumping speed at 50/60 Hz |
cfm |
1.4 / 1.6 |
| Ultimate partial vacuum (abs.) |
mbar |
4 x 10-4 |
| Ultimate vacuum (abs.) |
mbar/torr |
2 x 10-3 / 1.5 x 10-3 |
| Ultim. vac. (abs.) with gas ballast |
mbar/torr |
1 x 10-2 / 0.75 x 10-2 |
| Water vapor tolerance with gas ballast |
mbar |
40 |
| Ambient temperature range (operation) |
°C |
12 - 40 |
| Ambient temperature range (storage) |
°C |
-10 - 60 |
| Oil capacity (B-Oil) min./max. |
l |
0.1 / 0.25 |
| Max. back pressure (abs.) |
bar |
1.1 |
| Inlet connection |
|
Small flange KF DN 16 |
| Outlet connection |
|
Hose nozzle DN 8-10 mm |
| Rated motor power |
kW |
0.18 |
| Rated motor speed at 50/60 Hz |
min-1 |
1500/1800 |
