| General Specifications |
| Vacuum: |
-0.095MPa to 0MPa, at the local atmosphere is 0.1MPa.
Pressure is displayed in absolute pressure. The conversion between absolute pressure and vacuum is: Vacuum value = local atmosphere - set absolute pressure value. |
| Pressure: |
0MPa ~ 7MPa (pressure is displayed in gauge pressure) |
| Vacuum pressure limit: |
User-selectable low and high set point limits.
Vacuum will ber generated until the vacuum pressure is in between the low and high set point values and then remain in a standby state. |
| Positive pressure limit: |
User-selectable low and high set point limits.
Pressure will be generated until the pressure is in between the low and high set point values and then remain in a standby state. |
| Media: |
Air |
| Suction flow: |
9L/min |
| Power Supply: |
100W to 250V 50/60 Hz |
| Dimensions: |
21.7" x 17.3" x 9.3" LWH - (550 x 440 x 235 mm) |
| Weight: |
69.7 lbs (31.6 kg) |
| Outlet port: |
G1/8F |
| Storage temperature: |
-20°C to 70°C |
