| General Specifications |
| Media |
Air. |
| Generated Pressure Range |
95% vacuum to 1500 psi (100 bar) positive pressure |
| Adjustment Resolution |
0.001 psi (10 Pa, 0.1 mbar). |
| Material |
Ram/adapters: SS
Body: SS/aluminum
Seals: Buna-N |
| Connection |
Hand-tight connectors for both test gauge and reference gauge. |
| Test Gauge Connection |
1/4NPT female, 1/4BSP female, or M20X1.5 female
Reference Gauge Connection: 1/4NPT female, 1/4BSP female, or M20X1.5 female |
| Dimensions |
Height: 5.5" (140 mm)
Base: 12.4" (315 mm) x 7.8" (198 mm) |
| Weight |
5.7 lb (2.6 kg) |
| Warranty |
1 year |
