| General Specifications |
| Media: |
Air |
| Generated Pressure Range: |
95% vacuum to 2,000 psi (140 bar) positive pressure |
| Adjustment Resolution: |
10 Pa (0.1 mbar/0.0015 psi) |
| Material: |
Ram/adapters: SS
Body: SS/aluminum
Seals: Buna-N |
| Connection: |
Hand-tight connectors for both test gauge and reference gauge.
Test Gauge Connection: 1/4NPT female, 1/2NPT female, 1/4BSP female, or M20X1.5 female
Reference Gauge Connection: 1/4NPT female, 1/2NPT female , 1/4BSP female, or M20X1.5 female |
| Dimensions: |
Height: 7.00" (178 mm)
Base: 21.26" (540 mm) x 10.63" (270 mm) |
| Weight: |
14.3 lb (6.5 kg). |
| Warranty: |
1 year |
