| General Specifications |
| Media |
Oil or deionized water.
(Oil is default media liquid. Pump with water as media to be ordered specifically) |
| Generated Pressure Range |
85% vacuum to 10,000psi (700bar) positive pressure. |
| Adjustment Resolution |
0.001 psi (10 Pa, 0.1 mbar). |
| Material |
Ram/adapters: SS
Body: SS/aluminum
Seals: Buna-N |
| Connection |
Hand-tight connectors for both test gauge and reference gauge. |
| Test Gauge Connection |
1/4NPT female, 1/4BSP female, or M20X1.5 female
1/4NPT female, 1/4BSP female, or M20X1.5 female |
| Dimensions |
Height: 5.31" (155 mm)
Base: 11.42" (290 mm) x 7.8" (198 mm) |
| Weight |
7 lb (3.2 kg) |
| Warranty |
1 year |
