| General Specifications |
| Media: |
Oil |
| Pressure Range: |
85% vacuum to 15,000psi (1,000bar) positive |
| Material: |
Ram/adapters: SS
Body: SS/aluminum
Seals: Buna-N |
| Connection: |
Hand-tight connectors for both test gauge and reference gauge(s).
1/4NPT female, 1/2NPT female, 1/4BSP female, 1/2BSP female, or M20X1.5 female |
| Dimensions: |
Height: 9.1" (230 mm)
Base: 20.5" (520 mm) x 14.2" (360 mm) |
| Weight: |
35.2 lb (16 kg) |
| Warranty: |
1 year |
