| General Specifications |
| Media: |
Compatible to phosphoric acid ester fluid and Skydrol Oil (should not be used for mineral oil) |
| Reservoir capacity: |
420 ml (25.6 in3) |
| Pressure Range: |
85% vacuum to 15,000 psi (1,000bar) positive |
| Material: |
Ram/adapters: SS
Body: SS/aluminum
Seals: EPDM,PTFE,Copper Alloy |
| Connection: |
Hand-tight connectors for both test gauge and reference gauge.
Test Gauge Connection: 1/4NPT female, 1/4BSP female, or M20X1.5 female
Reference Gauge Connection: 1/4NPT female, 1/4BSP female, or M20X1.5 female |
| Dimensions: |
Height: 9.1" (230 mm)
Base: 20.5" (520 mm) x 14.2" (360 mm) |
| Weight: |
35.2 lb (16 kg) |
| Warranty: |
1 year |
| Piston volume |
Low pressure piston: 30 ml (1.8 in3 )
High pressure piston: 2.5 ml (0.15 in3 ) |
