| General Specifications |
| Media: |
Oil |
| Pressure Range |
0 to 60,000psi (4,200bar) gauge pressure. |
| Reservoir capacity: |
420ml (25.6 in^3) |
| Material: |
Ram/adapters: SS
Body: SS, aluminum, copper
Seals: Buna-N, PTFE, Copper Alloy, Aluminum Alloy |
| Connection: |
Test Gauge Connection: Positional Autoclave F-250-C, 9/16" - 18 UNF female
Reference Gauge Connection: Positional Autoclave F-250-C, 9/16" - 18 UNF female
1/2BSP female and M20X1.5 female connections are available upon request. |
| Dimensions: |
Height: 6.9" (175 mm)
Base: 17.9" (455 mm) x 15.0" (380 mm) |
| Weight: |
33.1 lb (15 kg). |
| Warranty: |
1 year |
| Piston volume: |
Fine adjust piston: 1.5 ml (0.09 in^3) |
