| Rated capacity |
200 kPa ~ 50 MPa |
| Safe overload |
200 %R.C. |
| Ultimate overload |
300 %R.C. |
| Accuracy |
0.2 %R.O. (including non-linearity, hysteresis and repeatability) |
| Rated output |
Current : 4 mA ~ 20 mA (2 wires method, Load resistance 500 ohm or less, at 24 V)
Voltage : 0 V ~ 10 V (Load resistance 5 k-ohm or more) |
| Response frequency |
1 kHz |
| Power supply voltage |
DC 24 V(18 V ~ 28 V) |
| Power consumption |
Approx. 30 mA |
| Insulation resistance |
1 000 MΩ or more (DC 50 V) |
| Temp. range, compensated |
-20 ℃ ~ 70 ℃ |
| Temp. range, safe |
-30 ℃ ~ 80 ℃ |
| Temp. effect on zero |
0.2 %R.O./10 ℃ |
| Temp. effect on output |
0.2 %LOAD/10 ℃ |
| Cable |
φ4.7, 2 m shielded cable directly attached,
Cable end separated (Cable attached type) |
| Connector |
R03-RB5F(receptacle) |
| Class of protection |
IP44 or equivalent |
| Material of pressure hole |
Stainless steel |
| Material of cover |
Alluminium alloy (with almite processing) |
| Material of pressure diaphragm |
Single crystal sapphire, etc., |
| Mounting screw |
G3/8{PF} |
| Weight |
Approx. 200 g |
| Tightening torque |
20 N･m ~ 40 N･m {2.04 kgf･m ~ 4.08 kgf･m} |
| Special specification |
NS100A-D6 : Guranteed accuracy 0.2 %R.O. at negative side. Power supply voltage : ±DC15 V
NS100A-H : As an amplifier part is are separated.(The highest, environmental temperature is 200 ℃)
NS100A-S70 : IP67 waterproof construction with zero adjustment factor)
NS102 : Pressure inlet port : φ10
|
| |
|
