| Output |
Voltage 0.5 … 10 V, 0.5 … 4.5 V
Current 4 ... 20 mA, 3 wire
Voltage 0.5 … 10 V, 0.5 … 4.5 V, tare function
Current 4 ... 20 mA, 3 wire, tare function |
| Measurement range |
up to ±180° (1 axis)
up to ±60° (2 axes) |
| Resolution |
0.05° |
| Linearity |
±0.5° |
| Sensing device |
integrated MEMS device |
| Housing material |
Stainless steel EN 1.4404 (AISI 316L) |
| Protection class |
IP68 (10 bar), continuous use |
| Connection |
Cable, standard length 2 m |
| Weight |
approx. 1,250 g (without cable) |
