| Output |
Voltage 0.5 … 10V, 0.5 … 4.5V
Current 4 ... 20 mA, 3 wire
CANBUS
SSI
Redundant second channel as option |
| Measurement range: |
0 ... 15° to 0 ... 360° (selectable in 15° increments)
SSI / CANBUS: 360° |
| Resolution |
Analog: 0.03 % (60 ... 360°), 0.1 % (15 ... 45°)
SSI: 12bit / 360°
CANBUS: 0.05° max. |
| Linearity |
±0.3% f.s. (typ)
SSI / CANBUS: ±1° (typ.) |
| Repeatability |
±0.03% (60 … 360°), ±0.1% (15 … 45°) |
| Housing material |
Aluminum |
| Protection class: |
IP67 / IP69 (with mating connector only) |
| Connection |
Male 5-pin socket M12
Male 8-pin socket M12
Cable output |
| Weight (without cable) |
approx. 40g
|
