| General Specifications |
| Analog Output |
Current output: DC 4~20mA (Max. load resistance: 250Ω)
Voltage output: DC 0~5V |
| Display Resolution (Model 6332D only) |
0.01m/s (Velocity Range: 0 to 2, 0 to 5, 0 to 10 m/s)
0.1m/s (Velocity Range: 0 to 25, 0 to 50 m/s) |
| Response Time |
Display: 0.3 second Sampling: 0.1 second Output: 0.1 second |
| Power Supply |
DC 12 to 24V |
| Operating Temperature Range |
41 to 104 ºF (5 to 40 ºC) with no condensation |
| Storage Temperature Range |
14 to 122°F (-10 to 50°C) with no condensation |
| Dimensions |
128(W)×78(D)×30(H) mm |
| Weight |
0.7 lbs (320g) |
| Warranty |
1 year |
| What’s Included |
Meter, Operation Manual |
| Airflow Transducer Probes (See Table Below) |
| Measurement Specifications |
| Air Velocity |
| Ranges |
0.1 to 25.0 m/s
0.1 to 50.0 m/s |
| Accuracy |
+/- (3% of READING +/- 0.1) m/s |
| Operating Temperature Range |
-4 to 158°F (-20 to 70°C) with no condensation |
| Storage Temperature Range |
14 to 122°F (-10 to 50°C) with no condensation |
| Warranty |
1 year |
| What’s Included |
Probe, Data ROM, NIST TRACEABLE CALIBRATION Certificate |
