| Rated Primary Current |
DC100mA |
| Applicable Current |
±1mA～±100mA |
| Max. Capable Current |
10A |
| CT Inside Diameter |
φ45mm |
| Output Voltage |
±2.5V F.S |
| Accuracy |
±1% F.S |
| Response Time |
Approx. 2s |
| Power Supply |
+24V±10%(Unipolar) |
| Power Consumption |
Approx. 17.5ｍA |
| Output Part |
Lead Wire： Approx. 150mm （with Connector：SMR-03V-B） |
| Wiring Method |
Red:+24V Black:COM White:Output Green:Ref |
| Rated Voltage |
Less than DC500V for low voltage circuit of coated wires |
| Withstanding Voltage |
AC2000V/1 minute (between output terminal and CT) |
| Insulation Resistance |
More than 100MΩ by 500V insulation tester (between output terminal and CT) |
| Operation Temperature |
-20～80℃, less than 80%RH w/o condensation |
| Dimension |
106×143×47mm
|
| Weight |
Approx. 1800g |
| Standard |
Compliant with RoHS directive
|
