| Rated Primary Current |
AC10A（50/60Hz） |
| Applicable Current |
1mA～10A |
| Max. Capable Current |
15A |
| Secondary Windings |
800Turns |
| CT Inside Diameter |
φ5.2mm |
| Applicable Frequency |
10Hz～5kHz |
| Output Example |
AC12.4mV±5%（1A/10Ω） |
| Capable CT Open/Close |
Approx. 100 times |
| Output Part |
Lead Wire： Approx. 2000mm （with Y Terminal ：V1.25-B3A） |
| Rated Voltage |
Less than AC600V for low voltage circuit of coated wires |
| Withstanding Voltage |
AC2200V/1 minute (between output terminal and outer case) |
| Insulation Resistance |
More than 100MΩ by 500V insulation tester (between output terminal and outer case) |
| Operation Temperature |
-20～70℃, less than 80%RH w/o condensation |
| Dimension |
49.1×42.5×22mm |
| Weight |
Approx. 95g |
| Standard |
Compliant with RoHS directive
|
