| Applicable Current |
8mA～25mA |
| Max. Capable Current |
25mA |
| CT Inside Diameter |
φ6mm |
| Output Example |
Open collector output (L (OFF) level at detection) |
| Operating current |
8mA |
| Detectable pulse width |
More than 10msec |
| Power Supply |
+12V±10%(Unipolar) |
| Output Part |
M3 Terminal |
| Wiring Method |
R1:Output R0:COM 12V:+12V |
| Rated Voltage |
Less than AC600V for low voltage circuit of coated wires |
| Withstanding Voltage |
AC2200V/1 minute (between output terminal and outer case) |
| Insulation Resistance |
More than 100MΩ by 500V insulation tester (between output terminal and outer case) |
| Operation Temperature |
-20～70℃, less than 80%RH w/o condensation |
| Dimension |
33×77×22mm |
| Weight |
Approx. 55g |
| Standard |
Compliant with RoHS directive
|
