| Rated Primary Current |
AC400A |
| Rated Secondary Current |
5A |
| Max. Capable Current |
480A |
| CT Inside Diameter |
37×34.5mm |
| Applicable Frequency |
50/60Hz |
| Comparative Error |
±1.0% In /±1.5% 0.2 In /±3.0% 0.05In |
| Phase Accuracy |
±1.0° In / ±1.5° 0.2 In / ±3.0° 0.05In |
| Overcurrent Intensity |
40 times （against Rated Primary Current） |
| Rated Burden (VA) |
5VA |
| Open Protection |
With output short-circuit switch
|
| Capable Mount/Dismount CT |
Approx. 100 times |
| Output Part |
M3 Terminal |
| Rated Voltage |
Less than AC600V for low voltage circuit of coated wires |
| Withstanding Voltage |
AC2200V/1 minute (between output terminal and CT) |
| Insulation Resistance |
More than 100MΩ by 500V insulation tester (between output terminal and CT) |
| Operation Temperature |
-10～50℃, less than 80%RH w/o condensation |
| Dimension |
127×95×40mm |
| Weight |
Approx. 540g |
| Standard |
Compliant with RoHS directive
|
