| Rated capacity (R.C) |
150gf, 300gf, 600gf |
1, 2, 3Kgf |
5, 10, 15, 30, 50Kgf |
| Rated output (R.O) |
1.2mV/V ±1% |
1mV/V ±1% |
1.5mV/V ±1% |
| Nonlinearity |
0.02% R.O. |
0.02% R.O. |
0.02% R.O. |
| Hysteresis |
0.02% R.O. |
0.02% R.O. |
0.02% R.O. |
| Repeatability |
0.02% R.O. |
0.02% R.O. |
0.02% R.O. |
| Creep |
0.03% R.O./20min |
0.03% R.O./20min |
0.02% R.O./20min |
| Zero balance |
±5% R.O |
±5% R.O |
±5% R.O |
| Terminal resistance input |
420 ±30Ω |
420 ±30Ω |
420 ±30Ω |
| Terminal resistance output |
350 ±2Ω |
350 ±2Ω |
350 ±2Ω |
| Insulation resistance |
2000MΩ |
2000MΩ |
2000MΩ |
| Temperature range, compensated |
0 ~ 40℃ |
-10 ~ 50℃ |
-10 ~ 50℃ |
| Temperature range, safe |
-10 ~ 50℃ |
-10 ~ 50℃ |
-10 ~ 50℃ |
| Temperature effect, on zero balance |
0.03% R.O./10℃ |
0.03% R.O./10℃ |
0.03% R.O./10℃ |
| Temperature effect, on rated output |
0.02% LOAD/10℃ |
0.02% LOAD/10℃ |
0.02% LOAD/10℃ |
| Excitation recommended |
10V DC |
10V DC |
10V DC |
| Safe overload |
150% R.O |
150% R.O. |
150% R.O. |
| Cable length |
ø3, core shield cable,
40cm |
ø3, core shield cable,
40cm |
ø3, core shield cable,
40cm |
