SUMM |
SUMMA |
| Rated capacity (R.C) |
1,2,5,10,20,50,100,200kgf |
1,2,5,10,20,50,100,200kgf |
| Rated output (R.O) |
0.7mV/V ~ 1.2mV/V |
0.7mV/V ~ 1.2mV/V |
| Nonlinearity |
0.1% R.O. |
0.1% R.O. |
| Hysteresis |
0.1% R.O. |
0.1% R.O. |
| Repeatability |
0.1% R.O. |
0.1% R.O. |
| Zero balance |
±2% R.O |
±2% R.O |
| Temperature effect, on rated output |
0.1% LOAD/10℃ |
0.1% LOAD/10℃ |
| Temperature effect, on zero balance |
0.05% R.O./10℃ |
0.05% R.O./10℃ |
| Temperature range, compensated |
-10 ~ 70℃ |
-10 ~ 70℃ |
| Temperature range, safe |
-10 ~ 80℃ |
-10 ~ 80℃ |
| Terminal resistance input |
350 ±30Ω |
350 ±30Ω |
| Terminal resistance output |
350 ±2Ω |
350 ±2Ω |
| Insulation resistance bridge/case |
2000MΩ |
2000MΩ |
| Excitation recommended |
5V |
5V |
| Safe overload |
120% R.C |
120% R.C |
| Cable length |
ø3.4core shield cable, 2m |
ø3.4core shield cable, 2m |
