| Output |
Potentiometer 1 kΩ
Voltage 0... 10 V, 0.5 … 10 V
Current 4 ... 20 mA, 2 or 3 wire
Voltage or current output, programmable (PMUV/PMUI)
SSI
CANopen
SAE J1939
Incremental encoder |
| Resolution |
Analog: essentially infinite
ADSI16: max. 16 bit f.s.
Incremental 10 P/mm , 25 P/mm |
| Linearity |
Up to ±0.05 % f.s. |
| Sensing device |
Precision potentiometer
Optical encoder
Magnetic absolute encoder |
| Housing material |
Zinc die cast, aluminum,
Measuring cable: stainless steel |
| Protection class |
IP65 (with mating connector only) |
| Connection |
Connector M12 |
| Weight |
Approx. 1.1 kg |
