| Output |
Potentiometer
Voltage 0... 10 V
Current 4 ... 20 mA, 2 or 3 wire |
| Resolution |
Analog: essentially infinite |
| Linearity |
Up to ±0.05 % f.s. |
| Sensing device |
Precision potentiometer |
| Housing material |
Aluminum
Measuring cable: stainless steel |
| Protection class |
Housing: IP65
Dust-EX-proof: II 3D Ex tc IIIC T80°C Dc |
| Connection |
Cable output, standard length 2 m |
| Weight |
1,500 mm approx. 1 kg, 2,000 mm approx. 1.5 kg |
| Explosion-proof |
DIN EN 60079-0 (September 2019)
DIN EN 60079-31 (December 2014) |
